Pro-source 2101015029PRO Oil Water Separator 425 Cfm

Product Description

The PRO-SOURCE 2101015029PRO is an oil-water filter/separator designed to remove oil contamination from compressed air system condensate. Rated for 425 CFM of airflow and up to 250 psi working pressure, it handles the condensate separation demands of industrial and commercial compressed air installations. A 40-micron sintered bronze filter media captures oil droplets and particulates before discharge. The manual drain and integrated sight glass allow the technician to monitor bowl fill level and drain accumulated condensate at the appropriate interval, making routine maintenance straightforward on busy service schedules.

This separator is used in compressed air systems where condensate must be treated before disposal to meet local environmental regulations. Typical installation points include downstream of air compressors, refrigerated dryers, or moisture separators where oil-laden condensate collects. The 1-1/2 inch NPT thread connection suits standard compressed air piping found in light industrial shops, manufacturing facilities, and large commercial HVAC mechanical rooms. A licensed mechanical contractor or qualified compressed air technician is the expected installer.

Key Features

• 425 CFM airflow capacity for high-demand compressed air systems
• 250 psi maximum working pressure rating
• 40-micron sintered bronze filter media for effective oil-water separation
• Manual drain with 29 oz steel bowl for condensate collection
• Integrated sight glass for visual monitoring of bowl fill level
• 1-1/2 inch NPT threaded inlet/outlet connection
• 160 degrees F maximum operating temperature

Compatibility

Designed as an OEM-style replacement or new-installation oil-water separator for compressed air systems with a 1-1/2 inch NPT connection and flow requirements up to 425 CFM at pressures up to 250 psi.

Installation Notes

Installation should be performed by a qualified mechanical contractor familiar with compressed air system piping and applicable local codes. Depressurize and lock out the compressed air system completely before removing any existing separator or making piping connections. Use appropriate thread sealant rated for compressed air service on all NPT connections. Verify that the inlet flow direction, drain orientation, and mounting position match system requirements before final tightening.
