Pro-source 2101005010PRO Oil Water Separator 160 Cfm

Product Description

The PRO-SOURCE 2101005010PRO is a compressed air oil-water separator designed for condensate separation in pneumatic systems. Rated at 160 CFM and 250 psi maximum working pressure, it removes oil and water from compressed air lines using a 40-micron sintered bronze filter element. The unit features a manual drain and an integrated sight glass for quick visual monitoring of the bowl level. Weighing 2.7 pounds and measuring 7.625 inches high by 3.75 inches wide, it is sized for inline installation in commercial and industrial compressed air distribution systems. A licensed air system technician or pipefitter typically handles installation.

This separator is intended for oil/water condensate separation in compressed air applications where moisture and compressor oil carryover must be removed before air reaches downstream tools, equipment, or processes. It connects via a 1/2-inch NPT threaded port, making it suitable for integration into standard compressed air piping networks. The 10-ounce zinc bowl provides adequate condensate capacity for moderate-duty cycles, and the sight glass allows service personnel to monitor accumulation without disassembly. It is appropriate for both light industrial and commercial pneumatic setups requiring reliable condensate management.

Key Features

• 160 CFM flow rating supports moderate to high-volume compressed air systems
• 250 psi maximum working pressure for compatibility with standard industrial compressors
• 40-micron sintered bronze filter element captures oil and particulate from condensate
• Manual drain with integrated sight glass for visual bowl level monitoring
• 1/2-inch NPT connection for straightforward inline installation
• Zinc bowl construction with 10-ounce capacity

Compatibility

Designed for inline installation in compressed air systems requiring oil/water condensate separation at 1/2-inch NPT connection points, with flow rates up to 160 CFM and operating pressures up to 250 psi.

Installation Notes

A licensed pipefitter or qualified air system technician should install this separator in compliance with applicable local mechanical codes. Depressurize and lock out the compressed air system completely before making any threaded connections. Apply thread sealant appropriate for compressed air service to the NPT fittings. Orient the unit so the bowl faces downward for proper condensate collection and manual drain access.
