Pro-source 2101005006PRO Oil Water Separator 100 Cfm

Product Description

The PRO-SOURCE 2101005006PRO is a manual-drain oil water separator designed for compressed air systems that generate oil and water condensate. Rated at 100 CFM and 250 psi maximum working pressure, this unit filters condensate through a sintered bronze element with a 40 micron rating before discharge. The zinc bowl holds 6 ounces and includes a built-in sight glass so technicians can monitor fluid accumulation without disassembly. The 1/2 inch NPT thread connection fits standard compressed air line fittings. Licensed HVAC technicians, industrial maintenance techs, and pneumatic system installers use this type of separator to meet environmental and equipment-protection requirements at compressor drain points.

This separator is suited for industrial and commercial compressed air installations where oil-contaminated condensate must be separated before discharge to drain. Typical applications include reciprocating and rotary screw compressor systems operating up to 160 degrees F. The manual drain design gives technicians direct control over condensate disposal intervals, making it appropriate for lower-volume condensate applications or locations where an auto-drain is not required. The 40 micron sintered bronze filter media captures oil aerosols and particulate carried in the condensate stream.

Key Features

• 100 CFM flow rating for compressed air condensate separation
• 250 psi maximum working pressure
• 40 micron sintered bronze filter media removes oil aerosols and particulate
• Sight glass included for visual monitoring of bowl fill level
• Manual drain with 6 oz zinc bowl for controlled condensate disposal
• 1/2 inch NPT inlet/outlet for standard compressed air line integration
• Rated to 160 degrees F maximum operating temperature

Compatibility

Designed as an OEM-style replacement or new-installation oil water separator for compressed air systems requiring condensate treatment at the drain point with 1/2 inch NPT connections and flow rates up to 100 CFM.

Installation Notes

Installation should be performed by a qualified technician familiar with compressed air piping systems. Depressurize the air line completely before installing or servicing this separator. Apply appropriate thread sealant to NPT connections and verify all joints are leak-free before returning the system to service. Dispose of collected oil water condensate in accordance with local environmental regulations, as oil-contaminated condensate is typically classified as hazardous waste.
