Prier C-534T08 C-534 Series Wall Faucet 8 inches 3/4 inches MPT x 1/2 inches FPT Inlet

Product Description

The PRIER C-534T08 is a C-534 series wall hydrant that provides a year-round source of water to areas subject to freezing temperatures. The hydrant connects to the supply piping in the heated portion of the structure, eliminating freezing. It combines freezeless hydrant features with self-draining, antisiphon, and two backflow check valves. This commercial wall hydrant is key operated and code approved.

• Double check valve and anti-siphon vacuum breaker
• Drains automatically with hose attached, even with hose attached
• Solid brass body, valve stem cap, seat and stem ends

Product Highlights

The PRIER C-534T08 wall hydrant features a vacuum breaker/backflow preventer that protects against cross-connection and flows up to 9 GPM. No special installation tools are required.

Product Information

Standard Information

• Brand: PRIER
• Manufacturer Part Number: C-534T08
• Country of Origin: USA

Technical Specifications

• Size: 3/4" x 1/2"
• Lead Free: No
• Anti-Siphon: Yes
• Application: Commercial
• Product Type: Wall Hydrant
• Length (Inches): 8"
• Material: Brass
• Inlet Diameter: .5, .75 in.
• Outlet Diameter: .75 in.
• Water Connection Type: FIP, MIP
• ASSE Code: 1052
• Certifications: ASSE, UPC
• Approved for Commercial Use: Yes
• Manufacturer: Prier
• Part Number: C-534T08
• Faucet Type: Wall Hydrant
• Length: 8 in
• Inlet Style: 3/4" MPT X 1/2" FPT
