Precision Electric Motor Sales SGR-1.375-SPLIT Adjustable Speed Motor

Product Description

The Precision Electric Motor Sales SGR-1.375-SPLIT is a reliable AC electric motor designed for industrial applications that need variable speed control and constant torque. It fits a standard NEMA frame, making it versatile for various installations.

• Designed for adjustable speed applications.
• Can be utilized for bypass operation.
• Features a wide speed range of 1000:1.

Product Highlights

This motor is ideal for industries requiring precise speed adjustments while maintaining stable performance. It operates effectively within various environments, meeting demanding operational needs.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: SGR-1.375-SPLIT

Technical Specifications

• Rated Motor Output Power: 7 1/2 HP (5.63 kW)
• Rated Motor Speed: 1800, 6000 RPM
• Rated Motor Voltage: 230V, 460V
• Rated Motor Current: 9.5 AMP
• Phase: 3
• Poles: 4
• Service Factor: 1
• Nominal Efficiency: 91.7%
• Nominal Power Factor: 81
• Leads (Qty, Size): 9 #14
• Frequency: 60 Hz
• Frame: 213TC
• Enclosure: TEBC
• Mounting Type: C-Face / Rigid
• Approximate Weight: 170 lb
• Frame Material: Cast Iron
• C-Dimension: 29.14
• NEMA Design: A
• Insulation Class: H
• Rotation: Reversible
• Duty: Continuous
• Ambient Temperature: 40 °C
• DE Bearing: 6307
• NDE Bearing: 6206
• Shaft Diameter: 1.375
• Shaft Length: 3.375
• Grease Type: Polyrex EM
• Greaseable: No
