Precision Electric Motor Sales SGR-0.625-SPLIT General Purpose Motor

Product Description

The Precision Electric Motor Sales SGR-0.625-SPLIT is a three-phase general purpose motor suitable for various industrial applications. This motor is inverter duty capable and supports multiple mounting styles including F1, F2, and F3. It has combination mounting holes and options for shaft grounding rings, brakes, drip covers, and lint guards. This motor is built for continuous duty and is efficient in operation.

• Inverter duty capable.
• Configurable for F1, F2, and F3 mounting.
• Rolled steel frame ensures durability.

Product Highlights

This motor is ideal for heavy industrial use, ensuring reliable performance under continuous duty. It is compatible with various mounting styles, providing flexibility in installation.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: SGR-0.625-SPLIT

Technical Specifications

• Phase: 3
• Output HP: 0.50
• Output KW: 0.37
• Voltage: 208-230/460
• Speed: 1140 RPM
• Service Factor: 1.25
• Frame: 56HC
• Enclosure: Drip Proof
• Efficiency: 81.7%
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 2.1 A
• Power Factor: 57
• Duty: Continuous
• Insulation Class: F
• Rotation: Reversible
• Mounting: Bolt-on Base
• Shaft Diameter: 0.625 inches
• Drive End Bearing Size: 6203
