Precision Electric Motor Sales PVQT-400

Product Description

The Precision Electric Motor Sales PVQT-400 is an OEM replacement motor suited for direct drive blower applications. This motor operates on one hundred fifteen volts and one point five amps, providing a power of one-tenth horsepower. It features two speeds and a rotation speed of one thousand fifty RPM, making it efficient for various air movement tasks.

• Engineered as an OEM replacement motor for direct drive blower applications.
• Equipped with automatic overload protection and sleeve bearing design for reliability.
• Features PSC motor type with open air over enclosure and cULus approval.

Product Highlights

This motor ensures functionality and safety with its automatic overload protection. Its designed sleeve bearings help maintain operational integrity.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: PVQT-400

Technical Specifications

• HP: 1/10
• Volts: 115
• Amps: 1.5
• RPM: 1050
• Speed: 2
• Insulation Class: B
• Ambient Temperature: 40°C
• HZ: 60
• Bearing Type: Sleeve Bearing
• Motor Type: PSC
• Enclosure: Open Air Over
• Capacitor Included: 5MFD/370VAC
