Precision Electric Motor Sales H360B Contactor

Product Description

The Precision Electric Motor Sales H360B is a definite purpose contactor essential for various industrial applications. This 3-pole contactor is capable of managing locked rotor amps of three hundred sixty, three hundred, and two hundred forty, in addition to resistive amps up to seventy-five. With a coil voltage of one hundred twenty VAC, it supports horsepower ratings reaching thirty HP at six hundred Volts in three-phase configurations. The compact dimensions of the unit measure three point twenty-five by one point seventy-six by two point ninety-nine inches, making it suitable for tight spaces.

• Definite purpose contactor
• 3-pole configuration
• Includes mounting plate and quick connect terminals

Product Highlights

This contactor serves a range of HVAC and electrical applications, ensuring reliable performance.

Product Information

Standard Information

• Country of Origin: United States of America
• Weight: 1.40 LB

Technical Specifications

• Poles: 3
• Locked Rotor Amps: 360 / 300 / 240
• Resistive Amps: 75
• Coil Voltage: 120 VAC
• Coil VA Inrush 60 Hz: 120
• Coil VA Sealed 60 Hz: 16
• Coil VA Inrush 50 Hz: 129
• Coil VA Sealed 50 Hz: 17.5
• Horsepower 120V 1 Phase: 5
• Horsepower 208V 1 Phase: 7.5
• Horsepower 240V 1 Phase: 7.5
• Horsepower 208V 3 Phase: 25
• Horsepower 240V 3 Phase: 25
• Horsepower 480V 3 Phase: 30
• Horsepower 600V 3 Phase: 30
• Dimensions: 3.25 x 1.76 x 2.99
