Precision Electric Motor Sales D294P Fasco D294 Direct OEM Replacement Motor

Product Description

The Precision Electric Motor Sales D294P is a direct OEM replacement motor for the Fasco D294 model. This model features a one-tenth horsepower rating and operates at 1050 RPM with a voltage of 115. It is suitable for fan coil air conditioners and unit heater fan applications.

• Designed for energy efficiency with a new PSC design.
• Includes a 5MFD/370 VAC capacitor for better performance.
• Constructed with sleeve bearings and open ventilation as an air-over type motor.

Product Highlights

The D294P motor is designed for effective cooling and heating operations in residential settings.

Product Information

Standard Information

• Manufacturer: Precision Electric Motor Sales
• Replaces Models: Fasco D294, 7186-0020

Technical Specifications

• Horsepower: 1/10 hp
• RPM: 1050 RPM
• Speeds: 5-Speed
• Amps: 1.5 amps
• Voltage: 115 Volts
• Frequency: 60hz
• Diameter: 5 inches
• Shaft Size: 10 x 3/8 x 10
• Motor Length Without Shafts: 3.30 inches
• Shaft Height: 3.50 inches
• Bearings: Sleeve Bearings
• Ventilation: Open ventilation - Air Over
• Capacitor Included: 5MFD/370 VAC Capacitor
• Mount Type: Resilient Mount - Base Included
