Precision Electric Motor Sales D277P Fan Coil Air-Conditioning and Heating Unit Motor

Product Description

The Precision Electric Motor Sales D277P is a Permanent Split Capacitor motor designed as a direct OEM aftermarket replacement for the FASCO D277. This motor operates as a fan coil air-conditioning and heating unit motor, as well as a dual wheel blower motor. The motor runs at 277 volts and features a three-speed operation at 1050 RPM with a rating of 1/10 horsepower. Its open ventilation design enables efficient air flow, while sleeve bearings enhance its performance.

• Direct OEM aftermarket replacement for FASCO D277
• Operates at 1050 RPM with 1/10 HP
• Includes a capacitor for efficient performance

Product Highlights

This motor is ideal for use in fan coil air conditioners and unit heaters, providing reliable operation in various heating and cooling applications.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: D277P

Technical Specifications

• HP: 1/10 HP
• RPM: 1050 RPM
• Speeds: 3-Speed
• Amps: 0.6 Amps
• Volts: 277 Volts
• Frequency: 60Hz
• Shaft Size: 8.5 x 1/2 x 8.5 Double Shaft
• Motor Diameter: 5 inches
• Motor Length Less Shafts: 3.50 inches
• Mounting: Resilient Mount
• Mounting Ring Diameter: 2.44 inches
• Bolt Circle: 4.62 inches
• Bearings: Sleeve Bearings
• Enclosure: Open Ventilation - Air Over
• Motor Type: PSC (Permanent Split Capacitor)
• Frame: 42Y Frame
• Thermally Protected: Yes
