PRECISION ELECTRIC MOTOR SALES 4024A Self-Priming Water Pump 1.5 HP

Product Description

The Precision Electric Motor Sales 4024A is a self-priming water pump with a one point five horsepower motor. This pump is engineered for clean water applications in domestic settings, gardens, and light industrial tasks. It features a sturdy cast iron pump housing, making it durable for varied uses.

• Handles chemically neutral liquids efficiently.
• Can suction water up to eight meters deep.
• Ideal for irrigation and domestic water management.

Product Highlights

This self-priming pump is versatile for various applications, providing reliable performance for water transfer tasks.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: 4024A

Technical Specifications

• Model: RH-4024
• Power: 1.5 HP
• Input Voltage: 220-240 V
• Frequency: 50-60 Hz
• Minimum Flow: 2.4 m³/h
• Maximum Flow: 9.3 m³/h
• Minimum Head: 3 m
• Maximum Head: 45 m
• Inlet/Outlet Port Diameter: 1¼ x 1 in
• Suction Height: 8 m
• Speed: 2850 RPM
• Maximum Liquid Temperature: 60 °C
• Maximum Ambient Temperature: 40 °C
• Working Pressure: 4.5 BAR
• Protection Level: IP44
• Insulation Class: B
• Pump Housing Material: Cast Iron
• Motor Housing Material: Aluminum
• Mechanical Seal Material: Ceramic/Graphite
• Motor Protection: With
• Coil Winding Material: Copper
• Impeller Material: Brass
• Shaft Material: 316+45
