PRECISION ELECTRIC MOTOR SALES 3P200T4RM-56HC 2.0 Horsepower Electric Motor

Product Description

The PRECISION ELECTRIC MOTOR SALES 3P200T4RM-56HC is a 3-phase electric motor suitable for industrial use. It has a horsepower rating of 2.0 and operates at 1750 revolutions per minute in a 56HC frame. This motor can run on dual voltage of 230 or 460 Volts, making it versatile for different setups. Designed with Class F insulation, it offers thermal protection for added durability. Its Totally Enclosed Fan Cooled (TEFC) enclosure allows it to perform well in various conditions. A service factor of 1.25 indicates its ability to handle sustained overload, and it is capable of running in ambient temperatures up to 40 degrees Celsius. Additionally, the motor includes a removable base for easy installation.

• Operates as a 3-phase motor with 2.0 horsepower and 1750 RPM.
• Designed for 230/460 Volt input with Class F insulation.
• Features a TEFC enclosure and a removable base for installation flexibility.

Product Highlights

This motor is ideal for industrial applications needing reliable power in demanding environments.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: 3P200T4RM-56HC

Technical Specifications

• HP: 2.0
• RPM: 1750
• Voltage: 230/460 Volt
• Amps: 5.6/2.8
• Frame: 56HC
• Phase: 3-Phase
• Insulation: Class F
• Frequency: 50/60 HZ
• Ambient Temperature: 40 degrees Celsius
• Service Factor (SF): 1.25
• Enclosure: TEFC
• Base: Removable
• C-DIM: 13.06
