Precision Electric Motor Sales 3P150T4RM-56HC

Product Description

The Precision Electric Motor Sales 3P150T4RM-56HC is a 1.5 horsepower, 3-phase motor suitable for various industrial tasks. It operates efficiently at 1760 RPM and supports voltages of 230/460 Volts at both 50 and 60 Hz. This model features a Totally Enclosed Fan Cooled (TEFC) design that protects the motor from dust and moisture, ensuring a longer life.

• This 3-phase motor provides 1.5 HP at 1760 RPM.
• It has dual voltage capability of 230/460 Volts, suitable for both 50 Hz and 60 Hz applications.
• Include key features such as a TEFC enclosure, Class F insulation for heat resistance, and a removable base for easy installation.

Product Highlights

The 3P150T4RM-56HC is designed for reliable performance in demanding environments.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: 3P150T4RM-56HC

Technical Specifications

• Horsepower: 1.5 HP
• RPM: 1760
• Voltage: 230/460 Volt
• Amperage: 4.3/2.2
• Frame: 56HC
• Phase: 3-Phase
• Insulation Class: F
• Frequency: 50/60 Hz
• Ambient Temperature: 40°C
• Service Factor: 1.25
• Enclosure: TEFC
• Base: Removable
