Precision Electric Motor Sales 3P075T4RM-56C

Product Description

The Precision Electric Motor Sales 3P075T4RM-56C is a three-phase electric motor suitable for general purpose use. It delivers three fourths horsepower and operates at one thousand seven hundred sixty-five RPM. Constructed with a 56C frame, this motor features a Totally Enclosed Fan Cooled (TEFC) design that protects it from dust and moisture. It can operate on dual voltage systems at two hundred thirty or four hundred sixty volts and is built with Class F insulation which allows reliable function in temperatures up to forty degrees Celsius.

• Operates on three-phase power at 230/460 volts with Class F insulation.
• Includes a 56C frame, TEFC enclosure, and removable base.
• Delivers 3/4 horsepower at 1765 RPM with a service factor of 1.25.

Product Highlights

This motor is designed to handle moderate overloads and is ideal for various industrial and commercial applications.

Product Information

Standard Information

• Motor Type: Three-phase electric motor
• Power Output: 3/4 HP

Technical Specifications

• RPM: 1765
• C-DIM: 10.81
• Amps: 2.7/1.4
• Frame: 56C
• Phase: 3-Phase
• Voltage: 230/460 Volt
• Insulation Class: Class F
• Frequency: 50/60 HZ
• Ambient Temperature: 40°C
• Service Factor: 1.25
• Enclosure: TEFC
• Base: Removable
