Precision Electric Motor Sales 3P050T4RM-56C

Product Description

The Precision Electric Motor Sales 3P050T4RM-56C is a three-phase electric motor ideal for industrial use. This unit operates at 230/460 volts with a frequency of fifty or sixty hertz. It contains Class F insulation for dependable service in different thermal environments. The motor has a power rating of half a horsepower and runs at one thousand seven hundred seventy RPM. It is constructed with a 56C frame and features a Totally Enclosed Fan Cooled (TEFC) design to safeguard internal parts from external elements. The motor functions efficiently at ambient temperatures reaching forty degrees Celsius and offers a removable base for improved mounting options. This motor serves as a direct replacement for the Marathon G581.

• Operates on three-phase power at two hundred thirty or four hundred sixty volts.
• Includes Class F insulation and is rated for fifty to sixty hertz frequency.
• Comes with a TEFC enclosure and a removable base for flexible installation.

Product Highlights

Ideal for industrial applications with robust design and reliable performance.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: 3P050T4RM-56C

Technical Specifications

• Horsepower: 1/2
• RPM: 1770
• C-DIM: 10.81
• Amps: 2.0/1.0
• Frame: 56C
• Replaces: Marathon G581
• Phase: 3-Phase
• Voltage: 230/460 Volt
• Insulation: Class F Insulation
• Frequency: 50/60 HZ
• Ambient Temperature: 40°C AMB
• Service Factor (SF): 1.25
• Enclosure: TEFC
• Base: Removable Base
