Precision Electric Motor Sales 25U21T AC Inverter/Vector Motor

Product Description

The Precision Electric Motor Sales 25U21T is an AC Inverter/Vector motor suitable for adjustable speed applications within a standard NEMA frame. It allows operation across the line for bypass functionality.

• Designed for AC variable speed applications
• Can be operated across the line for bypass
• Features a 1000:1 speed range

Product Highlights

This motor provides constant torque at zero speed and is CSA certified for hazardous locations.

Product Information

Standard Information

• Manufacturer Part Number: 25U21T
• Rated Motor Output Power: 7.5 HP (5.63 kW)

Technical Specifications

• Rated Motor Speed: 1800, 6000 RPM
• Rated Motor Voltage: 230V, 460V
• Rated Motor Current: 9.5 AMP
• Phase: 3
• Poles: 4
• Service Factor: 1
• Nominal Efficiency: 91.7
• Frame: 213TC
• Enclosure: TEBC
• Mounting Type: C-Face / Rigid
• Approximate Weight: 170 lb
• Frame Material: Cast Iron
• C-Dimension: 29.14
• Insulation Class: H
• Rotation: Reversible
• Ambient Temperature: 40 °C
