Precision Electric Motor Sales 1902 20 HP Three Phase AC Motor

Product Description

The Precision Electric Motor Sales 1902 is a 20 horsepower three-phase AC motor made by US Motors. It operates at 60 Hz and runs at a speed of 1770 RPM. This motor is suitable for general-purpose applications, featuring a 256T frame size and keyed motor shafts. It can function with either 200-240 VAC or 400-480 VAC input, drawing 47 Amps at 200-240 VAC or 23.5 Amps at 400-480 VAC.

• 20 horsepower
• Three-phase AC motor
• 256T frame size

Product Highlights

This motor is designed for reliability and efficiency in various industrial settings.

Product Information

Standard Information

• Manufacturer: US Motors
• Model Number: U20P2D

Technical Specifications

• Horsepower: 20.0 HP
• Input Voltage: 200 - 240 VAC, 400 - 480 VAC
• RPM: 1770
• Frequency: 60 Hz
• Rated Current: 47 Amps @ 200 - 240 VAC, 23.5 Amps @ 400 - 480 VAC
• Motor Shaft: Keyed
• Frame Size: 256T
• Service Factor: 1.25
• Height: 12 inches
• Width: 12 inches
• Depth: 12 inches
• Weight: 250 lbs
• Warranty: 1 Year Manufacturer
