Precision Electric Motor Sales 1198 100 HP 3 Phase Induction Motor

Product Description

The Precision Electric Motor Sales 1198 is a three-phase induction motor rated at one hundred horsepower. It is built for severe duty applications and operates efficiently at four hundred sixty volts and sixty hertz, achieving around twelve hundred RPM. Constructed with a cast iron frame, it features a totally enclosed fan cooled design, making it suitable for continuous and inverter usage.

• Operates at 460V and 60 Hz with a speed of 1200 RPM
• Built with a durable 444T frame and totally enclosed fan cooled enclosure
• Ideal for continuous duty and inverter applications

Product Highlights

This motor is designed for demanding industrial environments. Its robust construction ensures reliability in various applications.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: 1198

Technical Specifications

• Phase: 3
• Output Power: 100 HP (75.0 kW)
• Input Voltage: 460 V
• Speed: 1190 RPM
• Service Factor: 1.15
• Frame Size: 444T
• Enclosure Type: Totally Enclosed Fan Cooled
• Efficiency: 95 %
• Temperature Rating: 40 °C
• Frequency: 60 Hz
• Input Current: 115.0 A
• Power Factor: 86
• Duty Cycle: Continuous
• Insulation Class: H
• KVA Code: G
• Drive End Bearing Size: 6319
• Frame Material: Cast Iron
• Shaft Diameter: 3.375 inches
• Motor Orientation: Horizontal
• UL Listed: Yes
• CSA Certified: Yes
• IP Rating: 56
