Precision Brand 16A4 Steel Shim Stock 6 inch x 100 inch Roll

Product Description

Precision Brand 16A4 is a steel shim stock that measures six inches wide, one hundred inches long, and is zero point zero zero four inches thick. This shim is made from cold rolled, low carbon steel with a full hard finish, specifically type 1008-1010. It is designed for applications requiring precision in hardness, flatness, and accuracy.

• Thickness, material type, and lot number are clearly marked on the shim
• Full traceability ensures quality and reliability
• Minimum burring and distortion when punched or sheared

Product Highlights

Ideal for tool and die setup, machine assembly, and various industrial applications.

Product Information

Standard Information

• Brand: Precision Brand
• MPN: 16A4

Technical Specifications

• Width: 6 inches
• Length: 100 inches
• Thickness: 0.004 inches
• Material: 1008-1010 Full Hard Steel
• Rockwell Hardness: RB90-100
• Thickness Tolerance: +/- 0.0005 inches
• Shim Type: Roll
• Weight: 0.72 pounds
