Potter Electric Signal pdc-612 Vibrating Bell 85db 6in 12VDC

Product Description

The POTTER ELECTRIC SIGNAL pdc-612 is a vibrating-type bell designed for fire alarm, burglar alarm, and general signaling applications. Operating on 12 volts DC, it delivers an 85 dB output level sufficient for audible alerting in typical indoor environments. The bell housing measures 6 inches in diameter and mounts directly to a standard 4-inch square electrical box. Its low power consumption makes it well suited for battery-backed or supervised alarm circuits where current draw is a factor. Licensed alarm installers and electricians are the primary trades who specify and install this device.

The pdc-612 is intended for indoor use in residential and light commercial alarm systems. It functions as an audible notification appliance in fire alarm or intrusion detection systems, as well as in general-purpose signaling circuits. The 4-inch square electrical box mounting footprint is a common rough-in standard, simplifying installation in new construction and retrofit projects alike.

Key Features

• Vibrating bell mechanism produces 85 dB audible output
• Operates on 12 volts DC with low current draw
• 6-inch bell diameter for broad sound projection
• Mounts on a standard 4-inch square electrical box
• Suitable for fire, burglar, and general signaling applications
• Rated for indoor use

Compatibility

Designed as an OEM-style replacement or new-installation audible notification appliance for indoor 12 VDC fire alarm, intrusion, and general signaling circuits that use a standard 4-inch square electrical box mounting configuration.

Installation Notes

Installation should be performed by a licensed electrician or certified alarm technician in accordance with NFPA 72 and applicable local codes. De-energize the alarm circuit and verify zero voltage before making any wiring connections. Confirm the supply voltage and polarity match the device ratings before powering the circuit. The unit is rated for indoor use only and should not be installed in wet or outdoor locations.

Technical Specifications

• Operating Voltage: 12 volts DC
• Sound Output: 85 dB
• Bell Diameter: 6 inches
• Mounting: Standard 4-inch square electrical box
• Location Rating: Indoor
• Bell Type: Vibrating

Standard Information

• Brand: POTTER ELECTRIC SIGNAL
• Manufacturer Part Number: pdc-612
