Potter Electric Signal osysu-1 Osy Valve Supervisory Switch

Product Description

The POTTER ELECTRIC SIGNAL osysu-1 is an outside screw and yoke valve supervisory switch designed to monitor the open position of OSY-type gate valves in fire protection systems. Part of the OSYSU series, the osysu-1 includes one set of SPDT (Form C) contacts, providing a supervisory signal when the valve moves from its fully open position. This device is installed by licensed fire protection contractors and alarm technicians as part of a compliant supervisory circuit in wet, dry, or pre-action sprinkler systems.

The osysu-1 is suited for commercial and industrial fire suppression installations where OSY gate valve position monitoring is required by NFPA 13 or local authority having jurisdiction. It mounts to most OSY valves sized from 2 inches to 12 inches (50mm to 300mm) in diameter. Some valves as small as 12.5mm may also be compatible. The tamper-resistant cover is secured with two screws that require a special removal tool, which is included with each unit.

Key Features

• Monitors open position of OSY-type gate valves for supervisory circuit compliance
• Single SPDT (Form C) contact set for supervisory alarm panel integration
• Fits most OSY valves from 2 inches to 12 inches in diameter
• Tamper-resistant cover with included special removal tool
• Part of the OSYSU series, with two-contact model also available (OSYSU-2)

Compatibility

Designed to mount on most OSY outside screw and yoke gate valves ranging in size from 2 inches to 12 inches (50mm to 300mm), and on some valves as small as 12.5mm. Confirm valve stem and body geometry before installation.

Installation Notes

Installation should be performed by a qualified fire protection contractor or licensed alarm technician in accordance with NFPA 72, NFPA 13, and local code requirements. Disconnect supervisory power and notify the monitoring station before servicing or replacing the switch. The tamper-resistant cover screws require the special tool supplied with the device — do not substitute standard fastener tools. Verify the valve is in the fully open position and the supervisory circuit registers normal before returning the system to service.

Technical Specifications

• Contact Configuration: Single SPDT (Form C)
• Valve Compatibility Range: 2 inches to 12 inches (50mm to 300mm)
• Weight: 2.3 pounds
• Tamper Resistance: Special tool required for cover removal (tool included)

Standard Information

• Brand: POTTER ELECTRIC SIGNAL
• Manufacturer Part Number: osysu-1
