Potter Electric Signal Co. Us RM-1000ECS Remote Microphone

Product Description

The POTTER ELECTRIC SIGNAL CO. US RM-1000ECS is a remote microphone unit supplied with the SB-8 surface-mounted back box. It serves as a remote annunciator component in fire alarm and life safety communication systems. The RM-1000ECS allows a central operator or responding personnel to broadcast voice messages or tones to designated zones from a location remote to the main fire alarm control panel. Installation is typically performed by licensed fire alarm technicians following NFPA 72 requirements and local authority-having-jurisdiction guidelines.

The RM-1000ECS is intended for use in commercial and institutional fire alarm voice evacuation systems where distributed or secondary microphone access points are required. The included SB-8 back box provides a surface-mount enclosure for applications where flush mounting is not practical, making the unit suitable for corridors, stairwells, command stations, and security desks. This type of remote annunciator is a common component in hotels, hospitals, schools, and multi-story commercial buildings.

Key Features

• Remote microphone function enables voice paging from locations away from the main fire alarm control panel
• Includes SB-8 surface-mount back box for flexible installation in finished or unfinished spaces
• Designed for integration into fire alarm voice evacuation and emergency communication systems
• Sold as a single unit per package

Compatibility

Designed as an OEM-style remote annunciator microphone for compatible Potter Electric Signal fire alarm voice evacuation control systems. Verify system compatibility with the fire alarm control panel documentation before installation.

Installation Notes

Installation must be performed by a licensed fire alarm technician in accordance with NFPA 72 and applicable local codes. Disconnect and lock out power to the fire alarm control panel and associated circuits before wiring the remote microphone. The SB-8 back box should be securely fastened to a structural surface prior to device mounting. Commissioning and operational testing of the remote microphone function must be completed after installation per system documentation requirements.
