Platsky 555112 Condenser Fan Motor 1/10 Hp 115V

Product Description

The PLATSKY 555112 is a condenser fan motor rated at 1/10 horsepower and 115 volts, designed for use in residential and light commercial HVAC condensing units. This motor drives the condenser fan blade to move air across the coil, rejecting heat from the refrigerant circuit. At 4.7 pounds and a compact footprint of 5.19 inches by 4.63 inches by 7.00 inches, it fits standard condenser fan deck configurations. Installation is performed by licensed HVAC technicians as part of routine motor replacement or system repair work.

The PLATSKY 555112 Model 360 is suited for split-system air conditioner and heat pump condensing units operating on single-phase 115-volt power. It is a direct replacement in applications requiring a 1/10 HP condenser fan motor of matching voltage and physical dimensions. Always verify shaft diameter, rotation, and mounting bolt pattern against the existing motor before installation.

Key Features

• 1/10 HP output suitable for standard condenser fan blade loads
• 115-volt single-phase operation for common residential service
• Compact dimensions of 5.19 inches x 4.63 inches x 7.00 inches aid drop-in replacement
• Lightweight at 4.7 pounds for easier overhead or rooftop unit service
• Model 360 designation for straightforward cross-reference identification

Compatibility

Designed as an OEM-style replacement condenser fan motor for residential and light commercial split-system air conditioners and heat pumps requiring a 1/10 HP, 115-volt motor with matching physical dimensions.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all electrical power to the condensing unit before removing the existing motor or handling wiring. Confirm shaft length, rotation direction, and mounting configuration match the replacement motor prior to installation. Follow local electrical codes and manufacturer wiring diagrams when reconnecting leads.

Technical Specifications

• Horsepower: 1/10 HP
• Voltage: 115 volts
• Dimensions (L x W x H): 5.19 inches x 4.63 inches x 7.00 inches
• Weight: 4.7 pounds
• UPC: 01012100606

Standard Information

• Brand: PLATSKY
• Manufacturer Part Number: 555112
