Platinum Tools tps200c poe++ tester up to 56V, 280W, 4-Pair poe

Product Description

The Platinum Tools TPS200C is an easy-to-use, pocket-sized tester for all varieties of PoE, up to 56 volts and 280 watts of power. Powered by the PoE circuit, the TPS200C requires no batteries. It can be used inline with an actual PoE device to measure current flow, or by itself in Powered Device (PD) Simulation mode to determine the maximum power available from the PoE power source.

• Measures DC voltage from 3.5 to 56 volts, and power up to 280 watts; also tests up to 4-pair PoE (IEEE 802.3bt Type 3)
• Easy-to-read, bright, scrolling OLED display
• Test PoE on active data cables without interrupting data flow

Product Highlights

This pocket-sized tester is ideal for testing, monitoring, and troubleshooting current to cameras, VOIP phones, access points, and other PoE-based devices.

Product Information

Standard Information

• Brand: Platinum Tools
• Manufacturer Part Number: TPS200C
• Country of Origin: China

Technical Specifications

• Brand Name: Platinum Tools
• Manufacturer Part Number: TPS200C
• Depth: 1"
• Width: 2.5"
• Height: 2.5"
• Manufacturer: Platinum Tools, Inc
• Product Type: PoE Tester
• ADI Part Number: TS-TPS200C
• Device Function: PoE Testing
• Network (RJ-45): yes
• Package Contents: PoE++ Tester\n2.1x5.5mm DC Patch Cable
• Number of Network (RJ-45) Ports: 2
• Style: Digital
• Power Source: Battery Powered
• Form Factor: Pocket
• DC Voltage Range: 3.5 to 56V
• Test/Measurement Functions: DC Voltage
• Features: Measures DC Voltage from 3.5 to 56 volts / power, Tests up to 4-pair PoE, Powered by PoE Circuit, No Batteries Required
• Display: Digital
• UPC: 849160013389
• Country of Origin: China
• Model: TPS200C
• Application/Usage: PoE Testing
