Piher 4050 Piston F Bar Clamp 50 cm Opening 12 cm Throat Depth 20 in Capacity

Product Description

The Piher 4050 Piston F Bar Clamp is a reliable clamp designed for various applications. This clamp offers a 50 cm opening and a 12 cm throat depth, ensuring it holds firm under pressure.

• Piston clamp with double threaded screw
• Non-slip brake for secure clamping
• Rolled spring steel bar

Product Highlights

This clamp is ideal for maintenance, welding, assembly, and general-purpose clamping. Its nodular cast iron jaws and epoxy paint-coated cast iron and steel body ensure durability and strength.

Product Information

Standard Information

• Brand: Piher
• MPN: 4050
• UPC: 8422473040505

Technical Specifications

• Opening Size: 50 cm
• Throat Depth: 12 cm
• Capacity: 20 inches
• Bar Thickness: 8 mm
• Bar Width: 35 mm
• Spindle Diameter: 1.1 inches
• Weight: 5.3 lb
• Body Material: Epoxy paint-coated cast iron; steel
• Handle Type: Steel bar
• Country of Origin: Spain
• Application: Maintenance, welding, assembly, and general-purpose clamping
• Max Jaw Opening: 20 inches
• Throat Depth: 4.7 inches
