Piher 12060 Extra Strong XXL Bar Clamp 24 in Capacity

Product Description

The Piher 12060 Extra Strong XXL Bar Clamp is engineered for heavy-duty applications. With a 24-inch capacity, this tool is ideal for maintaining constant pressure on various projects.

• Rolled spring steel bar for consistent pressure
• Nodular cast iron jaws
• Non-slip brake to prevent loosening

Product Highlights

This bar clamp features a piston clamp with a double-threaded screw, enhancing both pressure and speed. The grooved support surface on the fixed jaw ensures a secure grip on curved and angled pieces. It is suitable for maintenance, welding, assembly, and general-purpose clamping.

Product Information

Standard Information

• Brand: Piher
• MPN: 12060
• UPC: 8422473120603
• Country of Origin: Spain

Technical Specifications

• Weight: 21 lbs
• Height: 2 inches
• Width: 10.75 inches
• Length: 32 inches
• Bar Thickness: 12 mm
• Bar Width: 60 mm
• Handle Type: Steel Bar
• Opening Size (Max): 60 cm
• Spindle Diameter: 1.5 inches
• Throat Depth: 7.4 inches
• Material: Epoxy Paint Coated Cast Iron and Steel
• Application: Maintenance, Welding, Assembly, General Purpose Clamping
