Phoenix Contact 1019985 TMC 71C 20A Miniature Circuit Breaker

Product Description

The Phoenix Contact TMC 71C 20A Miniature Circuit Breaker has MPN 1019985. This circuit breaker is designed for supplementary protection in accordance with UL 1077 standards. It safeguards circuits from overloads with a short-circuit rating of 7.5 kA. This breaker is suitable for one-position installations and mounts on NS 35 DIN rails.

• Rated current of 20 A
• C tripping characteristic for effective performance
• Compatible with NS 35 DIN rails for straightforward installation

Product Highlights

The Phoenix Contact TMC 71C 20A is ideal for residential and commercial applications where circuit protection is essential.

Product Information

Standard Information

• Product Type: Circuit breaker
• Product Family: TMC 7

Technical Specifications

• Type: DIN rail module, one-piece
• Number of Positions: 1
• Rated Current: 20 A
• Tripping Method: Thermal-magnetic
• Rated Short-Circuit Switching Capacity: 7.5 kA (240 V AC/60 V DC), 5 kA (277 V AC)
• Operating Voltage: 277 V AC / 60 V DC
• Mechanical Service Life: 20000
• Electrical Service Life: 6000
• Width: 17.6 mm
• Height: 84.3 mm
• Depth: 75.9 mm (including DIN rail)
• Degree of Protection: IP20
• Ambient Temperature (Operation): -35 °C to 70 °C
• Conductor Cross Section (Rigid): 1 mm² to 35 mm²
• Connection Method: Screw connection
• Tightening Torque, Min: 2 Nm
