Pentair 150367 Bag Filter Housing 40 Gpm 1 in Npt

Product Description

The PENTAIR 150367 is a bag filter housing designed for liquid filtration in industrial, commercial, and water treatment applications. The housing accepts a size 2 filter bag and delivers a maximum flow rate of 40 GPM through a 1-inch NPT end connection. Constructed entirely of polypropylene for both the housing and head, the unit is built to handle mildly corrosive or chemical-process fluids where metal housings are not suitable. The opaque black body measures 23.8 inches in overall length and 7.25 inches in overall diameter, and the assembly weighs 9 pounds. It is typically installed by plumbing contractors, water treatment technicians, or industrial maintenance professionals.

This housing is suited for residential well water systems, light industrial process lines, and commercial water pre-filtration setups where a single-bag configuration meets flow and contamination load requirements. The 1-inch NPT connections make it compatible with standard pipe runs in most facility plumbing configurations. With a maximum working pressure of 100 psi and a maximum working temperature of 100 degrees F, it fits a wide range of ambient and low-temperature process environments. The polypropylene construction makes it a practical choice wherever iron, brass, or stainless housings would be cost-prohibitive or chemically incompatible.

Key Features

• Polypropylene housing and head for corrosion resistance in chemical or treated-water service
• Accepts size 2 filter bags for high-dirt-holding capacity
• 40 GPM maximum flow rate through 1-inch NPT end connections
• Rated to 100 psi maximum working pressure
• Opaque black body, 23.8 inches long and 7.25 inches in diameter
• Lightweight at 9 pounds for easy single-technician handling and mounting

Compatibility

Designed as an OEM-style replacement or new-installation bag filter housing compatible with standard size 2 filter bags in 1-inch NPT piped liquid filtration systems.

Installation Notes

Installation should be performed by a licensed plumber or qualified water treatment technician in accordance with applicable local plumbing codes. Shut off the upstream supply line and depressurize the system fully before opening the housing or making pipe connections. Use thread sealant tape rated for the process fluid on all NPT connections. Do not exceed the rated working pressure of 100 psi or working temperature of 100 degrees F, and ensure the housing is mounted in an orientation that allows for easy bag removal and drainage.
