Pentair 071366S Single Phase 5 HP Motor Replacement C-Series Commercial High Performance Pool and Spa Pump

Product Description

The Pentair 071366S single phase 5 HP motor is designed for use with Pentair C-Series commercial performance pool and spa pumps. Constructed in bronze for maximum strength and durability, this motor operates at 230-Volt, 60-Hertz. It is engineered to meet the rugged demands of the commercial pool industry.

• Single phase 5-horsepower motor replacement
• Fits Pentair C-Series commercial performance pool and spa pumps
• Operate at 230-Volt, 60-Hertz

Product Highlights

Genuine Pentair replacement motor with all bronze construction for strength and durability. Ideal for commercial pools.

Product Information

Standard Information

• Brand: PENTAIR
• Manufacturer Part Number: 071366S
• Country of Origin: United States

Technical Specifications

• Brand: Pentair
• Manufacturer: Pentair
• Product Type: ELECTRIC_MOTOR
• Model / MPN: 071366S
• Number of Items: 1.0
• Voltage: 230 V
• Horsepower: 5 Horsepower
• Frequency: 60 Hz
• Phase: 1
• Duty: Continuous
• Insulation Class: F
• Frame: 184TDZ
• Enclosure: Open Drip Proof
• Overload Protector: No
• Ambient Temperature: 40 °C
• UL: Recognized
• CSA: Y
• Electrical Type: Capacitor Start
• Poles: 2
• Rotation: Counterclockwise
• Mounting: Round
• Motor Orientation: Horizontal
• Drive End Bearing: BALL
• Opp Drive End Bearing: BALL
• Frame Material: Rolled Steel
• Shaft Type: Keyed
• Overall Length: 17.32 in
• Frame Length: 12.00 in
• Shaft Diameter: 1.000 in
• Shaft Extension: 3 in
• Current: 22.7 A
• Speed: 3530 rpm
• Service Factor: 1.15
