PENN V47AS-1C 2in 115-160 Water Valve

Product Description

The PENN V47AS-1C is a two-inch water regulating valve designed for commercial applications. This valve operates with an opening point adjustment range of one hundred fifteen to one hundred sixty degrees Fahrenheit, making it suitable for various heating systems.

• Capillary connection with six-foot length.
• Compatible with multiple refrigerants including R12 and R22.
• Features a four hole ASME flange connection type.

Product Highlights

This valve provides reliable temperature regulation for cooling and heating systems, ensuring optimal performance in different environments.

Product Information

Standard Information

• Brand: PENN
• MPN: V47AS-1C

Technical Specifications

• Capillary: Capillary
• Pipe Size: 2 inches
• Item Weight: 27.00 lbs per EA
• Valve Piping: Two-Way
• Connection Type: Four Hole ASME Flange
• Application Type: Commercial
• Refrigerant Type: R12, R22, R134A, R502, R404A, R507
• Temperature Action: Heating Only
• Opening Point Media: Temperature
• Connector Description: 6 FT capillary
• High Pressure Refrigerant: Non R410A
• Opening Point Adjustment Range: 115-160 F
