Penn-Union IPC4/02 Insulation Piercing Connector, 4/0 - 2/0 AWG

Product Description

The Penn-Union IPC4/02 Insulation Piercing Connector is designed for tap or splice applications. This connector is dual rated for insulated copper and aluminum wire. It is suitable for indoor or outdoor installations on energized conductors. The tap must not be under load during installation. The exclusive RED Turbo Spacer allows for easy tightening of the main conductor while keeping the tap side open.

• Easy to install with captive hardware, requiring only a single wrench
• Sealed connections with an integral rubber grommet
• Watertight installations that prevent corrosion

Product Highlights

This connector ensures no contact with live parts during installation and is rated for 600 V and 90° C applications.

Product Information

Standard Information

• Conductor Size: 4/0 to 2/0 AWG
• Type: Dual Rated

Technical Specifications

• Bolt/Stud Size: 1/2 in
• Color: Black
• Conductor Type: Aluminum/Copper
• Country of Origin: MX
• Dimensions: 1-7/8 in H x 1 in W
• Finish: Tin Plated
• Material: Copper
• Mfg Standards/Approvals: CSA Certified, RoHS Compliant, UL 453G, UL 486A/B, UL E6207 Listed
• Package Height: 1.431 in
• Package Length: 1.937 in
• Package Weight: 0.098 lb
• Package Width: 1.118 in
• Specifications: 13 ft-lb Torque 75 A Copper, 60 A Aluminum
• Temperature Rating: 90 deg C
• Voltage Rating: 600 VAC
