Penn-Union IPB-NA4-3S Aluminum Clear Pre-Insulated Power Bar - Three Ports 14 AWG - 4 AWG

Product Description

The PENN-UNION IPB-NA4-3S is an aluminum clear pre-insulated power bar with three ports and single sided conductor entry, accommodating 14 AWG to 4 AWG conductors. It is dual rated for aluminum and copper conductors and is rated for 600V, 90°C. Suitable for use in panel boards, cable trays, raceways, ducts and troughs.

• Manufactured from high strength aluminum alloy
• Pre-insulated at factory with high dielectric strength plastisol
• Pre-filled with oxide inhibitor to prevent oxidation

Product Highlights

This power bar features clear insulation for visual confirmation of conductor insertion and saves time by eliminating taping.

Product Information

Standard Information

• Brand: PENN-UNION
• Manufacturer Part Number: IPB-NA4-3S
• Country of Origin: USA

Technical Specifications

• L (in.): 1.99
• W (in.): 1.13
• H (in.): 1.25
• Hex Size: 1/8"
• Number of Conductors: 3
• Temperature Rating: 257 degree fahrenheit
• Maximum Voltage: 600 Volts
• Brand: Penn-Union
