PENN CONTROLS P170AB-2C Single Pressure Control 20-100 psi LPR

Product Description

The PENN CONTROLS P170AB-2C is a single pressure control designed for low pressure applications. It is suitable for low pressure cut-out control and capacity control in commercial refrigeration and air conditioning systems. This control is compatible with various refrigerants and can handle non-corrosive fluid applications as well.

• Durable all-steel case for rugged protection
• Selectable pressure range from twenty to one hundred pounds per square inch
• Universal mounting bracket included for easy installation

Product Highlights

This pressure control features NEMA 1 enclosure and is fully adjustable without removing the cover for convenient use. It maintains reliability in a variety of environments.

Product Information

Standard Information

• Brand: PENN CONTROLS
• MPN: P170AB-2C

Technical Specifications

• Voltage: 120 - 240 VAC
• Switching Action: SPST Open Low
• Pressure Range: 20 inHg - 100 lb/sq-in
• Maximum Differential: 7 - 50 lb/sq-in
• Maximum Overpressure: 325 lb/sq-in
• Maximum Working Pressure: 100 lb/sq-in
• Dimensions: 2-1/4 in L x 4 in W x 4-1/16 in H
