Product Description
Pelican IM3410-00001 is an iM3410 Storm long case designed to protect long items with 1.89 cu ft (interior 54.50 x 10.00 x 6.00 in) of storage. The case uses lightweight HPX resin construction, press and pull latches that lock automatically, an O-ring watertight seal, and padlockable hasps. It is available with foam and includes a Gore-tex purge vent for pressure equalization and protection from water and dust.
- Internal volume 1.89 cu ft; interior dimensions 54.50 x 10.00 x 6.00 in (138.43 x 25.4 x 15.24 cm)
- Injection molded HPX resin body, five press and pull latches, O-ring seal, and four padlockable hasps
- Automatic pressure equalization purge vent (Gore-tex membrane); weight approx. 18 lb (20 lb with foam); operating range -20 F to 140 F
Product Highlights
Watertight, dustproof, crushproof long case with press and pull latches, O-ring seal, purge vent, and foam-configurable interior.
Product Information
Standard Information
-
Brand: PELICAN
-
Manufacturer Part Number: IM3410-00001
-
Country of Origin: United States
Technical Specifications
-
Brand: Pelican
-
Manufacturer Part Number: IM3410-00001
-
Model: iM3410
-
Case Type: Storm long case
-
Internal Volume: 1.89 cu ft (0.05 m^3)
-
Interior Dimensions: 54.50 x 10.00 x 6.00 inches (138.43 x 25.4 x 15.24 cm)
-
Exterior Dimensions: 57.74 x 12.71 x 6.67 inches (146.66 x 32.28 x 16.94 cm)
-
Weight (as listed): 18 lb (8.16 kg)
-
Weight With Foam: 20.00 lbs (9.07 kg)
-
Weight No Foam: 18.00 lbs (8.16 kg)
-
Body Material: Injection molded HPX resin
-
Latch Material: Valox - Polybutylene Terephthalate (PBT) (alternative: Xenoy polyester/polycarbonate blend)
-
O Ring Material: EPDM
-
Pins Material: Stainless Steel (alternative: Aluminum)
-
Foam Material: 1.3/1.35 polyester
-
Purge Vent Material: Gore-tex membrane
-
Latches: Five press and pull latches
-
Padlockable Hasps: Four padlockable hasps
-
Handles: Three double-layered soft-grip handles
-
Purge Valve: Automatic pressure equalization valve
-
Padlock Hole Diameter: 0.37 inches (0.94 cm)
-
Operating Temperature Min: -20 F (-29 C)
-
Operating Temperature Max: 140 F (60 C)
-
Capacity Volume (Nom): 1.89 cu ft
-
Category: Storage Containers
