Pb Heat 90836 Burner Wiring Harness WBV-03 Riello

Product Description

The PB HEAT 90836 is a burner wiring harness designed for use in hydronic heating systems. It includes an EAD (Electronic Air Damper) connection and provides the electrical interface between the burner controls and the boiler system. This harness is a direct-fit component engineered for the WBV-03 boiler platform paired with a Riello burner. Installation is typically performed by licensed HVAC or hydronic heating technicians during burner service, controls replacement, or full boiler commissioning. The 90836 weighs 26 pounds and ships as Carton 20, with reference number 20186378 for cross-referencing with Peerless documentation.

This wiring harness is intended for residential or light commercial hydronic heating applications where a WBV-03 series boiler is installed with a Riello burner assembly. It is used when the original harness shows signs of heat damage, insulation failure, failed connections, or when a full burner controls assembly is being replaced. Proper harness routing and secure connector seating are essential for reliable burner ignition and safe system operation.

Key Features

• Includes EAD connection for electronic air damper integration
• Designed specifically for WBV-03 boiler with Riello burner configuration
• Carton 20 packaging designation for parts identification and ordering
• Cross-reference number 20186378 for Peerless parts documentation
• OEM-style replacement for reliable fit and function

Compatibility

Designed for use with the WBV-03 boiler platform equipped with a Riello burner. Reference Peerless parts documentation under number 20186378 to confirm fitment before installation.

Installation Notes

A licensed HVAC or hydronic heating technician should perform this installation. Always shut down the boiler, disconnect electrical power, and allow the system to cool before accessing burner wiring components. Inspect all connectors and terminals for corrosion or heat damage before installing the new harness. Work should comply with applicable local electrical codes and the boiler manufacturer's service documentation.

Technical Specifications

• Weight: 26 pounds
• Includes EAD: Yes
• Carton: 20
• Reference Number: 20186378

Standard Information

• Brand: PB HEAT
• Manufacturer Part Number: 90836
