Pass & Seymour TR5362RED 20A Construction Spec-Grade Tamper-Resistant Duplex Receptacle, Back and Side Wire, 125 VAC

Product Description

The Pass & Seymour TR5362RED is a 20 amp construction spec-grade tamper-resistant duplex receptacle. It features a dual mechanical shutter system designed to prevent the insertion of foreign objects, ensuring safety in various environments. The exclusive patented feature includes a circuit label on the face, enabling permanent circuit identification. The receptacle is equipped with an easily accessible break-off line-contact connecting tab, allowing for quick and simple split-circuit wiring.

• 20 amp, 125 VAC rating for reliable power distribution
• Tamper-resistant design for enhanced safety
• Back and side wire connection options for installation flexibility

Product Highlights

This receptacle is ideal for construction or renovation applications where safety is a priority.

Product Information

Standard Information

• Brand: Pass & Seymour
• Manufacturer: Pass & Seymour

Technical Specifications

• Type: Tamper Resistant Duplex
• Voltage Rating: 125 VAC
• Amperage Rating: 20 Amperes
• Number Of Poles: 2-Pole
• Number Of Wires: 3-Wire
• Material: Nylon
• Height: 3.28 Inches
• Width: 1.32 Inches
• Depth: 1.13 Inches
• Weight: 0.22 Pounds
• Mounting: Screw
• Standard: UL498, CSA C22.2 No. 42
• Environmental Conditions: Dry Location
• Country of Origin: MX
