Pass & Seymour TM83PLWCC 15 Amp 120/125 VAC 3-Way White Decorator Combination Switch and Pilot Light

Product Description

The Pass & Seymour TM83PLWCC is a 15 amp, 120/125 VAC combination switch and pilot light. This device combines a three-way switch with an indicator light in a white decorator style. It is designed for residential and commercial applications, ensuring reliability and ease of use.

• Impact-resistant face and body.
• External screw-pressure-plate back and side wired, compatible with #12 and #14 AWG.
• Clear identification of circuits for safety.

Product Highlights

This combination switch features a rounded back body to protect wires, enhancing safety. The device is RoHS compliant and designed with a patented split circuit tab for easy access.

Product Information

Standard Information

• Brand: Pass & Seymour
• Manufacturer: Pass & Seymour / Legrand

Technical Specifications

• Voltage: 120 Volt
• Amperage: 15 Amp
• Material: Thermoplastic
• Gang Type: 3
• Number of Gangs: 3 Gang
• Orientation: Vertical
• Height: 3.81 Inch
• Width: 1.29 Inch
• Depth: 1.59 Inch
