Pass & Seymour PTTR8300-LA 3-Phase Duplex Tamper-Resistant Wall Mount Straight Blade Receptacle

Product Description

Pass & Seymour® PTTR8300-LA is a tamper-resistant wall mount receptacle designed for 3-phase connections. This receptacle operates at 125 VAC and supports up to 20 A of electric current. It features two poles and three wires, making it suitable for various electrical applications.

• Designed for hospital-grade applications.
• Back and side wire terminal compatibility for easy installation.
• Constructed from thermoplastic to ensure durability.

Product Highlights

This receptacle includes advanced features such as a dual mechanical shutter system to prevent foreign object insertion and auto ground clips for reliable operation.

Product Information

Standard Information

• Manufacturer: Legrand
• Brand: Pass & Seymour®

Technical Specifications

• Voltage Rating: 125 VAC
• Amperage Rating: 20 A
• Number of Poles: 2
• Number of Wires: 3
• Type: 3-Phase Duplex Tamper-Resistant Wall Mount
• NEMA Rating: NEMA 5-20R
• Material: Thermoplastic
• Dimensions: 5.13 in L x 2 in W x 1.4 in H
• Terminal Type: Back/Side Wire
• Color: Light Almond
