Pass & Seymour PS811120LA Combination Switch/Receptacle 20 A (Each)

Product Description

The Pass & Seymour PS811120LA is a combination switch and receptacle designed for versatility in residential and commercial electrical applications. This specification grade unit is rated for 20 Amperes at 277 Volts AC and features a back and side wired installation option. The device includes a rocking paddle actuator and is encased in a durable NEMA WD-1/WD-6 rated enclosure.

• 20 A, 277 VAC electrical rating
• Impact-resistant polycarbonate construction
• Designed for wall mounting with a compact size

Product Highlights

This combination device is ideal for both new installations and replacement scenarios. It helps keep installation efficient and meets various industry standards.

Product Information

Standard Information

• Brand: Pass & Seymour
• Manufacturer: Legrand

Technical Specifications

• Actuator: Rocking Paddle Up/Down
• Color: Light Almond
• Enclosure: NEMA WD-1/WD-6
• Environmental Conditions: -40 to 115 deg C Operating Temperature
• Material: Polycarbonate
• Mounting: Wall
• Operating Cycles: 50000 Cycles
• Size: 1.29 in L x 1.59 in W x 3.812 in H
• Type: Back/Side Wired Specification Grade
• Electrical Ratings: 20 A, 277 VAC
• Number of Poles: 1
