Pass & Seymour CRB5262-RED Construction Spec-Grade Duplex Receptacle 15A 125V

LEGRAND
Brand: LEGRAND
SKU: CRB5262-RED
Availability: In Stock

Ships same day if ordered by 12 pm
$21.13
$21.13
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Pass & Seymour CRB5262-RED is a construction spec grade duplex receptacle. This back and side wired receptacle supports 15A and 125V. It features a corrosion-resistant, plated steel strap locked in to face and back body. Suitable for commercial applications.

  • Corrosion-resistant, plated steel strap locked in to face and back body
  • Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring
  • Impact-resistant nylon face and thermoplastic back body

Product Highlights

The Pass & Seymour CRB5262-RED duplex receptacle is ideal for commercial construction applications requiring a durable and reliable power connection.

Product Information

Standard Information

  • Brand: Pass & Seymour
  • Manufacturer Part Number: CRB5262-RED
  • Country of Origin: Mexico
Technical Specifications
Color
Red
Application Sector
Commercial
Product Line
Pass & Seymour
Country Of Origin
Mexico
Single Piece Plated Steel Mounting Strap
Yes
Wall Plate Included
No
Number of Receptacles
2
Outlet Type
Straight Blade
Standard
UL498, CSA C22.2 No. 42, FEDSPEC
UPC Number
785007210200
Product Depth US
0.78 in
Product Height US
2.635 in
Product Width US
1.322 in
cULus ListingNumber
E140596
cULus Listed
Yes
Amperage
15 A
Connection Location
Back and Side
Wire Connection Type
Screw Terminals
Dielectric Strength
Withstands 2000V minimum
Flammability
UL94 V2
Indoor/Outdoor
Indoor
NEMA Configuration Code
5-15R
Number of Poles
Double Pole
Number of Wires
3
Voltage
125.0 V
Wire Size
14 - 10 AWG
Temperature Rise
Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current
Operating Temperature
Maximum continuous +60°C, minimum -40°C without impact
Application
Construction
Mounting Type
Surface
Amperage Rating
15A
AWG Range
14 - 10 AWG
Ground
Grounding
Rated Voltage
125V
Color Family
Red
Height
2.635 in.
Depth
0.78 in.
Width
1.322 in.
Capacity
Duplex
Conductor Size
14-10 AWG
Connection Type
Back and Side Wired
Grade
Construction Specification
Material
Nylon
NEMA
5-15R
TC Connection
Back and side wire
Temperature Rating
-40 degrees C
Type
Receptacles
12-Digit UPC
785007210200
GTiN
00785007210200
Product UPC
78500721020
UNSPSC
39121406
Certifications
CULUS,FEDSPEC
Voltage Rating
125 V
Current Rating
15 A
Wiring Type
Back, Side
NEMA Configuration
5-15R
ECCN
EAR99
