Pass & Seymour CR20W Duplex Straight Blade Receptacle 125 VAC 20 A 2 Poles 3 Wires Replacement MPN

Product Description

The Pass & Seymour CR20W Duplex Straight Blade Receptacle offers reliability in electrical connections. Designed to handle 125 volts and up to 20 amps, it is suitable for general use in both residential and commercial settings. This device features two poles and three wires, ensuring a robust and secure connection.

• Durable thermoplastic body resistant to impact.
• Corrosion-resistant steel strap for lasting retention.
• Compatible with #10 to #14 AWG copper or copper-clad wire.

Product Highlights

Features an auto-ground clip for reliable grounding and tri-drive terminal screws for easy installation.

Product Information

Standard Information

• Manufacturer: Pass & Seymour
• MPN: CR20W

Technical Specifications

• Voltage Rating: 125 VAC
• Amperage Rating: 20 A
• Number of Poles: 2
• Number of Wires: 3
• Material: Thermoplastic
• Dimensions: 3.3 in H x 1.32 in W x 0.78 in D
• Temperature Rating: -40 to 50 °C
• NEMA Rating: NEMA 5-20R
