Pass & Seymour 696I Single Pole Three-Way Combination Switch 15 Amps 120/277 Volts

Product Description

The Pass & Seymour 696-I is a single pole, three-way combination switch. It operates at 15 amps and supports voltages of 120 to 277. This product is designed for user-friendly installation and features a toggle actuator for easy operation.

• Rated for 15 amps at 120/277 volts.
• Features a long-life pilot light with a neon lamp.
• Compatible with #12 and #14 AWG wire.

Product Highlights

This combination switch is ideal for both residential and commercial applications. Its compact design allows for two devices in the space of one and meets NEC requirements for grounding combination devices.

Product Information

Standard Information

• Brand: Pass & Seymour
• Manufacturer: Pass & Seymour / Legrand

Technical Specifications

• MPN: 696I
• Type: Combination, Double
• Color: Ivory
• Voltage: 120 Volt
• Amperage: 15 Amp
• Dimensions: 1.32 L x 0.94 W x 4.06 H in
• Operating Temperature: Maximum continuous +60°C, minimum -30°C
• Certifications: CULUS
