Pass & Seymour 696-W Combination Switch 15A 120/277 VAC

Product Description

The Pass & Seymour 696-W is a combination switch designed for residential and commercial use. It operates at 15 Amperes with a voltage rating of 120/277 VAC. This device features side wiring for #12 and #14 AWG, allowing multiple devices to fit in the same wall space.

• Easily accessible break-off separate or common feed
• Long-life red neon lamp in pilot light rated 1/25 Watt, 125V
• Meets NEC requirements for grounding combination devices

Product Highlights

This combination switch is a practical choice for minimizing space and enhancing accessibility. With its robust features, it ensures safe and effective operation.

Product Information

Standard Information

• Color: White
• Type: 3-Way Combo Device

Technical Specifications

• MPN: 696-W
• UPC: 785007696028
• Depth: 0.94 Inches
• Width: 1.32 Inches
• Height: 3.28 Inches
• Weight: 0.24 Pounds
• Contact Rating: 15 Amperes at 120/277 VAC
• Operating Temperature: -30° to 60° C
• Mounting: Screw
• Environmental Conditions: Dry Location
