Pass Seymour 690LAGCC6 Decorator Duplex Switch 15A 6 Pack

Product Description

The PASS SEYMOUR 690LAGCC6 is a decorator-style duplex single pole switch rated at 15 amps and 120/277 volts, designed for commercial and residential wiring applications. This device packs two single pole switches into the space of one standard decorator opening, making it a practical solution where switch density matters. The light almond finish blends with neutral wall plate schemes. Grounding is built in, and side-wire terminations keep installation straightforward. Each package contains 6 units.

This switch is suited for commercial offices, multi-unit residential buildings, retail spaces, and any installation where two independently controlled circuits must share a single gang cutout. The break-off tab allows the installer to configure the device for either a common feed shared between both switches or separate feeds for fully independent circuit control. The window box construction aids in wire management during rough-in and trim-out.

Key Features

• Two single pole switches fit into the space of one standard decorator gang opening
• Break-off tab allows separate or common feed configuration
• Rated 15A at 120/277V for compatibility with both standard and high-voltage lighting circuits
• Grounding switch design meets current NEC grounding requirements
• Side-wire terminations for fast, reliable connections
• Window box construction for easier wire management

Compatibility

Designed as an OEM-style replacement or new-installation decorator duplex single pole switch for standard single-gang wall boxes in residential and commercial lighting control applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the circuit at the breaker panel and verify zero voltage with a meter before handling any wiring. Use the break-off tab to select common or separate feed before securing the device in the box. At 277 volts, confirm wire insulation ratings and box fill calculations comply with NEC Article 314 requirements.
