Pass & Seymour 5862W Heavy Duty Spec-Grade Duplex Receptacle 20A 250 VAC

Product Description

The Pass & Seymour 5862W is a heavy-duty spec-grade duplex receptacle, designed for reliable electrical connections in commercial settings. It has a voltage rating of two hundred fifty (250) VAC and an amperage rating of twenty (20) amperes. This receptacle is suitable for back and side wire installation, making it versatile for various applications.

• Durable construction with a brass strap for improved strength.
• Designed with strap tabs that wrap around the face to prevent separation.
• Compatible with #14 to #10 AWG copper or copper-clad conductors.

Product Highlights

This receptacle features a nylon construction, ensuring durability in dry locations. The design allows easy access for wiring, providing a secure and efficient setup. It meets multiple standards including RoHS, CSA, and UL.

Product Information

Standard Information

• Brand: Pass & Seymour
• Manufacturer: Pass & Seymour

Technical Specifications

• Type: Spec Grade Receptacle
• Color: White
• Depth: 0.78 inches
• Width: 1.32 inches
• Height: 2.64 inches
• Weight: 0.25 pounds
• Material: Nylon
• Mounting: Screw
• Voltage Rating: 250 VAC
• Amperage Rating: 20 Amperes
• Number of Poles: 2-Pole
• Number of Wires: 3-Wire
• Environmental Conditions: Dry Location
