Pass & Seymour 4760 Turnlok NEMA Single Receptacle 15A 277VAC 3-Wire

Product Description

The Pass & Seymour 4760 Turnlok NEMA single receptacle is designed for industrial applications requiring reliable performance. This receptacle operates at 15 amperes and 277 volts, making it ideal for heavy-duty electrical connections.

• Compact, impact-resistant nylon construction for durability.
• Clearly marked NEMA configurations for easy identification.
• High-grade brass contacts ensure good conductivity and resistance to heat.

Product Highlights

This receptacle features a one-piece, solid brass mounting strap and back wire capability. It is suitable for various wiring tasks in a safe, dry environment.

Product Information

Standard Information

• Brand: Pass & Seymour
• Manufacturer: Pass & Seymour

Technical Specifications

• MPN: 4760
• UPC: 785007476002
• Voltage Rating: 277 VAC
• Amperage Rating: 15 A
• NEMA Rating: L7-15R
• Number of Poles: 2
• Number of Wires: 3
• Material: Nylon
• Dimensions: 4 in Diameter x 4.031 in Height x 1.437 in Width x 1.203 in Depth
• Temperature Rating: -40 to 75 deg C
• Weight: 0.25 lbs
• Environmental Conditions: Dry Location
• Wire Size: 14 to 10 AWG
• Connection: Back and Side Wire
