Pass & Seymour 22200 Retrofit Brace, Premium Grade

Product Description

The Legrand Pass & Seymour 22200 Retrofit Brace is a premium grade fan support designed for easy installation and reliable performance. This brace can accommodate spans from 16 inches to 24 inches and is UL listed for both fan and fixture support. It features rotating dual support that allows for flexibility in installation, making it a top choice for professional electricians and contractors.

• UL listed for fan and fixture support
• Self-leveling feet for stable installation
• Maximum weight rating suitable for 16-inch spans

Product Highlights

This retrofit brace includes pre-installed ground screws and top knockouts to facilitate wiring. Its durable steel construction ensures long-lasting performance, while the deep box design provides ample space for wiring connections.

Product Information

Standard Information

• Brand: Pass & Seymour
• Part Number: 0149-7051

Technical Specifications

• UPC: 085129222007
• Type: T-Bar Box Hanger
• Color: Silver
• Depth: 2.5 inches
• Width: 3.63 inches
• Height: 4.33 inches
• Length: 15 inches
• Weight: 3.09 pounds
• Material: Steel
• Mounting: Ceiling
• Standard: UL Listed, Conforms to NEMA OS1
• Cubic Capacity: 25 Cubic Inches
• Buy American Compliant: No
• RoHS Indicator: C
• Country of Origin: CN
• Insulated: No
