Parlec ER32-S018 ER32 Collet Set 18 Piece

Product Description

The PARLEC ER32-S018 is an 18-piece ER32 collet set designed for use in ER32-compatible tool holders on CNC machining centers, manual mills, and lathes. The set covers a clamping range of 2.00 mm to 20.00 mm in 1 mm increments, providing broad coverage for common round-shank tooling. Each collet conforms to the ER32 collet system standard, making this set a practical shop supply for facilities running metric tooling programs. The complete set weighs approximately 1 pound and is packaged as a single unit.

This collet set is suited for production and job-shop environments where metric shank tooling is standard. Typical applications include end mills, drills, reamers, and taps held in ER32 collet chucks on vertical machining centers and CNC turning equipment. The 18-piece configuration covers sizes from 3.00 mm through 20.00 mm plus a 2.00 mm collet, eliminating the need to source individual collets for most metric tooling diameters encountered in general machining work.

Key Features

• 18 collets covering 2.00 mm to 20.00 mm in 1 mm steps
• ER32 collet system - fits any ER32-standard collet chuck
• 1 mm increment spacing provides full metric shank coverage
• Complete set packaged as a single unit for easy inventory management
• Lightweight kit at approximately 1 pound total

Compatibility

Designed for use with ER32-series collet chucks and tool holders conforming to the ER collet system standard.

Installation Notes

Installation is performed by a machinist or tooling technician. Ensure the spindle is fully stopped and the machine is in an e-stop or locked-out state before changing collets. Seat the collet fully into the nut before inserting the tool shank, and torque the collet nut to the chuck manufacturer's specified value using the appropriate spanner wrench. Inspect collet bore and taper surfaces for chips or wear before each use to maintain runout accuracy.
