Parlec DA200-0203 Double Angle Collet DA200 13/64

Product Description

The PARLEC DA200-0203 is a double angle collet designed for use in DA200 series collet chucks on CNC machining centers and manual milling machines. It holds round shank tooling with a clamping range of 0.1875 to 0.2031 inches, making it suited for 13/64 inch shank cutters, drills, and reamers. The collet measures 1.187 inches in overall length and 0.539 inches in overall diameter. Machinists and toolroom technicians install these collets as part of a quick-change or standard toolholding setup where secure, concentric grip on cutting tools is required.

This collet is used in production and job-shop machining environments where DA200 series collet chucks are already in service. Typical applications include milling, drilling, and light reaming operations on vertical machining centers and knee mills. The 13/64 inch capacity makes it a standard choice when tooling shank diameters fall at or just below 13/64 inch. It is appropriate for both light-duty production runs and general toolroom work where consistent tool holding is needed.

Key Features

• DA200 series collet - fits DA200 collet chucks directly
• Clamping range of 0.1875 to 0.2031 inches accommodates 13/64 inch shank tooling
• Overall length of 1.187 inches for standard DA200 chuck engagement
• Overall diameter of 0.539 inches
• Double angle design provides positive axial and radial grip on tool shanks

Compatibility

Designed for use with DA200 series collet chucks. Accepts round shank tooling with shank diameters from 0.1875 to 0.2031 inches.

Installation Notes

Installation is performed by a machinist or toolroom technician. Ensure the spindle is fully stopped and the machine is in a safe, powered-down state before changing collets. Clean the collet and chuck bore of chips and coolant residue before seating the collet to maintain runout accuracy. Do not exceed the collet clamping range, as over-clamping or under-clamping reduces grip force and can damage the collet body.
