Parker XV500CS-4 Manual Ball Valve 1/4 Inch Fnpt Carbon Steel

Product Description

The PARKER XV500CS-4 is a standard 2-piece manual ball valve designed for inline shutoff and flow control in industrial and mechanical piping systems. Built with a carbon steel body and trim, it handles up to 2000 psi working pressure through a 1/4 inch FNPT x FNPT end connection. The lever handle provides quick quarter-turn operation, making it a practical choice for systems requiring frequent manual isolation. Licensed HVAC technicians, pipefitters, and industrial service professionals install this valve in gas, hydraulic, and compressed-air applications where a compact, high-pressure shutoff is required.

This valve is suited for residential and light commercial mechanical systems as well as industrial piping where a 1/4 inch female NPT connection is specified. Typical install scenarios include compressed air distribution, hydraulic lines, refrigerant isolation, and gas service piping where a reliable inline shutoff is needed. The 2-piece body construction allows for straightforward inline installation without disassembling the surrounding piping.

Key Features

• 2000 psi maximum working pressure for high-pressure service applications
• 2-piece carbon steel body and trim construction for durability in demanding environments
• 1/4 inch FNPT x FNPT end connections for direct threaded inline installation
• Reinforced PTFE seat and seal material for chemical resistance and long service life
• Quarter-turn lever handle for fast, positive shutoff

Compatibility

Designed as an OEM-style replacement or direct-install manual ball valve for 1/4 inch female NPT threaded piping systems operating within the rated 2000 psi pressure range.

Installation Notes

Installation should be performed by a licensed pipefitter, plumber, or qualified HVAC technician in accordance with applicable codes such as the IFGC or IPC. Shut off and depressurize the system fully before removing any existing valve or fitting. Apply appropriate thread sealant to NPT connections and torque to the fitting manufacturer's recommendation for the pipe size and material. Do not exceed the rated working pressure of 2000 psi.
